OR-32SDMI – 3×2 Full 4K Matrix with USB-C, HDMI & SDM module inputs and HDMI outputs with USB Ethernet Hub
OR-32SDMI – 3×2 Full 4K Matrix with USB-C, HDMI & SDM module inputs and HDMI outputs with USB Ethernet Hub
The OR-32SDMI is a 3×2 matrix switch for use in a wide range of multi-format signals where the 3rd input is a SDM module slot for use with any SDMI (input) based modules, such as the SDM-WPS-HP wireless presentation module.
With the commonly used HDMI outputs, this unit can switch video signals between HDMI, USB-C and the desired installed input module.
This matrix switcher supports HDCP2.2, resolutions up to 4k@60Hz (4:4:4, 8-bit), and can be controlled via WebGUI, Telnet and RS-232. It also includes USB3.0 hub with two host-ports and two device-ports for flexible KVM configuration. With the USB extension, this product is ideal for conference, remote meeting, and education scenarios.
- Features
- 3 x 2 HDMI output matrix with USB-C, HDMI and SDM module slot inputs
- One input module card slot for CYP SDM series module cards. Look for SDM- product codes
- Supports USB 3.0 with one USB-B port, one USB-C port for connecting to a host PC, and two USB-A ports for peripheral devices and storage extension.
- Supports gigabit Ethernet
- Supports pass-through of 8 channel LPCM, bitstream & HD bitstream audio formats.
- Supports 4K HDR formats by HDR10, HLG and Dolby Vision
- Supports basic signal event automation (via RS-232, IP or CEC)
- Specification
Inputs 1x HDMI [1x HDMI Uncompressed AV and Data]
1x USB-C [1x USB-C USB-C / Thunderbolt]
1x SDM input module slot [1x Multi use SDM input module slot]
1x Phoenix (3 pin) [1x RS-232]
1x USB Type B [1x USB Propriety Data]
1x RJ45 [1x IP Control]Outputs 2x HDMI [2x HDMI Uncompressed AV and Data]
1x 3.5mm Stereo mini-jack [1x Analogue Stereo(L/R)]
2x USB Type A [2x USB Propriety Data]PSU 24V/5A Dimensions 231.5mm [W] x 25mm [H] x 158mm [D] Net Weight 900g Gross Weight 2300g - Downloads
OR-32SDMI Manual
