EL-7500V - [EOL] HDMI/VGA/YUV/CV to HDMI / VGA and HDBaseT Presentation Switch (48v)
EL-7500V - [EOL] HDMI/VGA/YUV/CV to HDMI / VGA and HDBaseT Presentation Switch (48v)
(EOL) The EL-7500V is an advanced rack-mountable HDMI, VGA, Composite and Component presentation switcher. This device can scale and switch input sources to its HDMI, VGA and HDBaseT™ outputs, with their associated audio signals to the native resolutions supported by the connected display. Control is via the IR remote, RS-232, IP, WebGUI or via manual selection buttons with OSD (On Screen Display). Both digital and analogue stereo audio is supported via a built-in DAC (Digital to Analogue Converter) and ADC (Analogue to Digital Converter).
(EOL) The HDBaseT output provides great versatility to extend your audio and video up to 70 metres over a single run of Cat.5e/6/7 cable. The HDBaseT output can provide 48V PoH power to compatible HDBaseT Receivers.
(EOL) The EL-7500V is the perfect solution for any educational or commercial environment requiring integration of multiple sources and signal formats to multiple simultaneous output formats.
- Features
- HDMI 1.3 and DVI 1.0 compatible
- HDCP 1.1 compliant
- Multiple video and audio inputs: 3 HDMI, 3 VGA, 1 Component Video, 1 Composite Video, and 8 Stereo audio
- Supports switching and scaling of multiple AV inputs for display over mirrored HDMI, HDBaseT and VGA outputs
- Supports input and output resolutions up to 1080p/WUXGA (RGB)
- Supports pass-through of LPCM 2.0 audio
- Supports 3D de-interlace, noise reduction, and 3D comb filtering for composite video sources
- Frame rate conversion support
- Supports analogue to digital (ADC) and digital to analogue (DAC) audio conversion, Em-Bedding & De-Embedding
- Quick output resolution switching via hot keys
- HDBaseT feature support: HD Video and Audio, Ethernet, 48V PoH, and Control (bidirectional IR/RS-232 pass-through)
- HDBaseT output provides 48V PoH to compatible HDBaseT Receivers
- Supports EDID and HDCP management
- Remote control provides discrete input source selection
- Specification
Inputs 3x HDMI [3x HDMI Uncompressed AV and Data]
3x 15pin Dsub [3x VGA RGBHV]
3x RCA [1x YUV YPbPr Component / YCbCr Component]
1x RCA [1x Composite]
4x RCA [2x Analogue Stereo (L/R)]
6x 3.5mm Stereo mini-jack [6x Analogue Stereo(L/R)]
1x 3.5mm Stereo mini-jack [1x Infra Red Receiver]
1x RJ45 [1x LAN Serving]
1x USB Type A [1x Service Port Propriety Data]
2x 9pin Dsub [2x RS-232 Data]
1x 15pin Dsub [1x VGA RGBHV]Outputs 1x HDMI [1x HDMI Uncompressed AV and Data]
1x RJ45 [1x HDBaseT HDMI & Propriety Data]
1x 3.5mm Stereo mini-jack [1x Analogue Stereo(L/R)]
1x RCA [1x Coaxial 2 Channel LPCM]
1x 15pin Dsub [1x VGA RGBHV]
1x 3.5mm Stereo mini-jack [1x Infra Red Emitter]PSU: 24V/6.25A Dimensions 432mm [W] x 183mm [D] x 44mm [H] Net Weight 2.20kg Gross Weight 3.10kg - Downloads
EL-7500V Manual
