EL-7300 - HDMI/VGA/Displayport Presentation Switch & Scaler

EL-7300 HDMI/VGA/Displayport Presentation Switch & Scaler
Hover over the image to zoom

CYP

EL-7300 - HDMI/VGA/Displayport Presentation Switch & Scaler

Close reviews

Leave a review

The EL-7300 is a compact and versatile presentation switch featuring Display Port, HDMI and VGA inputs. Any one of these inputs can be switched and scaled to your preference to the mirrored HDMI outputs. Independent audio signals can be routed with the VGA inputs of the switch. Audio can also be De-embedded at the output stage via the analogue or digital audio (ADC Conversion) outputs. The user can control the switch via IR remote, RS-232, WebGUI, Telnet or the front panel controls with OSD (On Screen Display). The EL-7300 is the perfect solution for any educational or corporate environment where AV system flexibility is essential.

  • Features
    • v1.3 HDMI, HDCP 1.1 and DVI 1.0 compliant
    • Integrate and switch HDMI, VGA, and Display Port sources to dual HDMI outputs
    • Audio de-embedding
    • Digital to Analogue & Analogue to Digital Audio conversion (DAC/ADC)
    • Detection of native screen resolution (EDID based)
    • Resolutions Supported : HDTV: 480i to 1080p plus 1080p 60fps PC: VGA to WUXGA
    • Audio Support : Dolby Digital, Dolby DTS, Dolby Digital Plus, Dolby True HD, DTS-HD Master Audio, LPCM Multi-channel, LPCM Stereo, Analogue Stereo
    • Telnet, IR Remote, RS-232, Push Button Control
    • On Screen Display (OSD) and WebGUI
    • Hotkey output resolution support
    • Supports EDID and HDCP Management
  • Specification
    Inputs 2x HDMI [2x HDMI  Uncompressed AV and Data]
    2x 15pin Dsub [2x VGA RGBHV]
    3x 3.5mm Stereo mini-jack [3x Analogue Stereo(L/R)]
    1x 9pin Dsub [1x RS-232 Data]
    1x RJ45 [1x IP Control]
    1x USB Type A [1x Service Update Propriety Data]
    1x Display Port [1x Display Port Uncompressed Video]
    Outputs 2x HDMI [2x HDMI Uncompressed AV and Data]
    2x 3.5mm Stereo mini-jack [2x Analogue Stereo(L/R)]
    1x RCA [1x Coaxial 2 Channel LPCM]
    PSU: 24V/2.7A
    Dimensions 215mm [W] x 153mm [D] x 42mm [H]
    Net Weight 1.051kg
    Gross Weight 1.501kg
