CR-KP4 - 8-Button Control Keypad (Black or White)

CYP CR-KP4 8-Button Control Keypad
Hover over the image to zoom

CYP

CR-KP4 - 8-Button Control Keypad (Black or White)

Close reviews

Leave a review

The CR-KP4 is a  versatile and useful product for both system integrators and smart home users alike. This 8-button keypad can send commands to any Ethernet controlled or relay controllable device in your system. The buttons are suitable for all environments and PoE (Power over Ethernet) support allows for creative placement of the keypad within your space without needing to be concerned about keeping it near a live power source. Additionally, the integrated clock and calendar based scheduling feature allows you to trigger macros to control devices within your installation at a specific time, or on a recurring schedule. The sophisticated appearance makes this keypad an elegant and decorative addition to your living or working space.

  • Features
    • 1-Gang wall plate design with tri-colour LED buttons
    • 32 macros for controlling user equipment
    • Up to 128 total commands can be stored and used across all macros in the system (up to 16 per macro)
    • Supports time and date macro scheduling (single and recurring)
    • Supports condition checking within macro commands for expanded macro design flexibility
    • Supports one month of backup power for the internal clock and schedule function to protect against blackouts and temporary power loss
    • Supports customisable daylight savings time configuration
    • Can be powered by an Ethernet switch that supports the IEEE 802.3af PoE standard (Optional)
    • Controllable via keypad, Telnet and WebGUI
  • Specification
    Inputs 1x RJ45 [1x Network IP Control]
    POE PSU: PoE
    PSU: 5V/2.6A
    Net Weight (B) 180g (W) 180g
    Gross Weight (B) 500g (W) 500g
SKUCR-KP4
£0.00
£270.60
